Φ5.5×115m Lateritic Nickel Rotary Kiln

Technical Parameters ofΦ5.5×115m Lateritic Nickel Rotary Kiln:

Name	Description	Unit
Equipment name	Rotary kiln
Specification	Φ5.5×115m
Application	Roasting laterite ores
Amount	1	Set
Output	80－100(roasted sand)	t/h
Driving mode	Double driving
Type of thrust roller	Hydraulic thrust roller
No. of support	4
Slope ( sine)	3.0%
Rotating speed
Driving mode	Bilateral double-driving
Main driving	0.2~1.2	r/min
Auxiliary driving	6.7	r/h
Sealing mode of kiln head	Sheet steel (provisional)
Sealing mode of kiln end	Air cylinder
Cooling of kiln head	Air cooling
Rotating direction	Clockwise (from discharging end)
Total weight	1648 ( excluding feed and discharge cover)	t
Temperature of discharged materials	750~850	℃
Temperature of waste gases	200~400	℃
Thickness of refractory bricks	230	mm
